Frame
M5 Alloy chassis and rear-end, Trail Geometry for 27.5 Front" and 26" rear wheels, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 140mm of travel
Seat Binder
Alloy, 38.6mm
Rear Shock
Marzocchi Bomber Air, Ride Dynamics Trail Tune, 2-position non-indexed compression sweep, w/ LSR adjustment, 210x50mm
Fork
Marzocchi Z1, GRIP damper, two position Sweep adjustment, 15x110mm Kabolt axle, 37mm offset, 140mm of travel
Front Brake
SRAM Code R, 4-piston caliper, hydraulic disk, 200mm
Rear Brake
SRAM Code R, 4-piston caliper, hydraulic disk, 180mm
Shift Levers
SRAM NX Eagle, trigger, 12-speed
Rear Derailleur
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Chain
SRAM NX Eagle, 12-speed
Crankset
SRAM X1 Eagle, DUB,155mm, 55CL, 30T
Chainrings
Steel, 30T
Bottom Bracket
SRAM DUB Threaded Wide
Rims
Roval Traverse, hookless alloy, 30mm inner width, tubeless ready. Front: 27.5", Rear: 26"
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.3"
Rear Tire
Butcher, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 26x2.3"
Inner Tubes
Standard, Presta valve
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Stem
Alloy Trail Stem, 35mm bar bore
Grips
Deity Grips
Saddle
Bridge Saddle, steel rails, 130mm
Seatpost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm, 100mm
Product ID
221411
Weight
15.31 kg (33 lb, 12.0 oz)
Weight Size
S3
